Algodue · Rogowski coil accessory

MFC140/F — Ø7 mm Flexible Rogowski Coil with Built-in Integrator

Ø7 mm flexible Rogowski coil with a built-in integrator — 333 mV full-scale output for lower currents (200 A–1 kA). Connects straight to a 333 mV input; no external RPS integrator required.

The Algodue MFC140/F is an Ø7 mm flexible Rogowski coil with a built-in integrator, delivering a 333 mV full-scale voltage output. Unlike the passive MFC140 (which needs a separate RPS integrator), the /F connects directly to a measuring instrument or inverter that accepts a 333 mV Rogowski signal. It covers the lower full-scale currents — 200 A (15 cm), 250 A (28 cm), 600 A (40 cm) and 1 kA (50 cm); the larger Ø8 mm MFC150/F covers 1–5 kA. Each coil ships with a 3 m cable.

Ø7 mm · built-in integrator · 333 mV full-scale
