Algodue · Three-phase metering
UEM6C — Three-Phase MID Energy Meter (CT-input, Ethernet)
Three-phase CT-input MID energy meter (EN 50470-3 Class C) with built-in Ethernet.
The Algodue UEM6C (UEM6C-A E) is a three-phase MID energy meter for CT-input applications, certified to EN 50470-3 Class C. It is self-powered from the measured voltage circuit and provides built-in Ethernet communication and 1 S0 pulse output. DIN-rail mounted. Current transformers (6A secondary) are not included. MID certified.
EN 50470-3 Class C
CT-input (6A secondary)
Built-in Ethernet
1 S0 pulse output
SKU 1113.0021.0001
$853AUD
In Stock
Qty
1
EN 50470-3 Class C · MID certified · Ethernet · DIN-rail mount
Technical detail
UEM6C specifications
Electrical & communication
PhaseThree-phase
Current inputCT-input, 6A secondary (CTs not included)
Voltage input3×230/400V 50Hz
Power supplySelf-powered (voltage circuit)
CommunicationEthernet
Outputs1 S0 pulse output
AccuracyEN 50470-3 Class C
CertificationMID
MountingDIN rail
Specifications per the Algodue UEM6C-A E product documentation. Current transformers (CTs) are not included and must be sourced separately.
